Breakout AOC

800G OSFP800 - 2x OSFP800

Key Features

  • Data rate: 53.125 GBd per lane
  • 8 channels of 100G-PAM4 modulation
  • Finned-top for 8-channel side, Flat-top for 4-channel side shell
  • Single 3.3 V power supply
  • Low power consumption:14W for 8-channel, 7 W for 4-channel
  • Up to 50 m with OM4 fibers
  • Hot pluggable
  • Management interface: CMIS 5.1
  • Commercial operating case temperature range:
    0 to 70°C
  • RoHS/REACH compliant
  • LSZH, LSZH/OFNR or OFNP-rated cable















Applications

  • InfiniBand NDR, IEEE 802.3ck 400GAUI-4
  • Datacenter: servers, switches, storages
    ,and other adapter cards
  • Proprietary HPC interconnections












Request for a data sheet
